Single-phase linking gateway Hoymiles 100a HiBox-100S-G3

Benefits of the monophasic link gateway Hoymiles HiBox-100S-G3

The catwalk Hoymiles HiBox-100S-G3 Simplifies intelligent power flow control in single-phase self-consumption systems. Designed to support 100 A of Maximum Current in CA at nominal tensions of 220 V, 230 V or 240 V, this unit allows directly connecting the public network rush and feed all the consumption of the household without having to split circuits or install additional crucies of critical charges. Dimensions 535 x 490 x 170 mm and a weight of 17 kg, your chassis for wall mount It optimizes the technical space while maintaining a clean and functional aesthetic.

Its most outstanding differential feature is the ability to offer a Backup time of 0 ms in combination with the inverters and lithium batteries series Hoymiles Hione. This instant transfer avoids restarts on computers, medical equipment or sensitive domotic systems during unforeseen falls of the electric network. When integrating this smart catwalk with solar panels set by solar High quality, customers Tienda Solar They ensure a reliable and continuous energy management system.

Multifuente management with smart port of 100A and fast shutdown

The HiBox-100S-G3 Acts as a versatile central node for the integration of heterogeneous generation sources. Has a Programmable intelligent port (gene / Inverter FV / Smart Load) Designed to manage currents up 100 a. This entry allows you to attach a Diesel generator or auxiliary gasoline, Automating its start and stop according to the state of charge of the accumulators, or integrate inverters Third-party Solar and even manage smart charges (as heat pumps or electric vehicle chargers).

Additionally, it admits the direct connection of up 2 inverters range with a maximum current of 54.5 a. In terms of operational protection, it integrates a Quick shutdown function (Rapid Shutdown), which allows instantaneously interrupting energy sources in case of emergency to isolate installation and prevent electrical or fire risks.

IP54 protection, silent dissipation and official guarantee

Built to operate in demanding environments, the catwalk HiBox-100S-G3 It has a protection index Ip54, offering high resistance to dust and water splash in covered areas or garages. Your thermal dissipation system works by Natural Convection No Fans, eliminating operational noise and reducing mechanical maintenance. It works stably in a temperature range of -30 ° C to +55 ° C and altitudes up 4,000 meters.

The team communicates through the Protocol Rs485, by sending real-time telemetry to the manufacturer's monitoring system. Has a Official guarantee of 5 years Backed directly by the manufacturer. To learn more about link gateway connection schemes, assembly and integration guides with Inverters solar, we invite you to visit the Blog Tienda Solar.

Detailed technical characteristics

• Product model: Hoymiles HiBox-100S-G3

• Form of the electrical network: Monophasic L / N / PE

• Nominal AC voltage (Network / Backup): 220 V / 230 V / 240 V

• Nominal AC Frequency: 50 Hz / 60 Hz

• Maximum AC current (Network / Backup): 100 a

• Backup switching time (Backup): 0 ms (without interruption with inverters and Hione batteries)

• Maximum number of connections inverter: Up to 2 inverters

• Maximum current of input AC inverter: 54.5 a

• Smart port (gene / Inverter FV / Loads): 1 dedicated connection (up to 100 A max.)

• Integrated security function: Quick shutdown (Rapid Shutdown) from power sources

Frequently Asked Questions (FAQ)

1. How is the switching time of 0 ms in the Hoymiles HiBox-100S-G3?

The Switching time 0 ms It is achieved through ultra fast coordination between the catwalk Hibox and the inverters and accumulators of the series Hoymiles Hione. This guarantees that before a network failure the housing burdens do not perceive microcortes or restart.

2. Is it necessary to modify the electrical installation to isolate the critical charges?

Not. Thanks to the catwalk admits a Maximum current of 100 A, allows the Full backup of the whole house (Whole Home Backup) Connecting all the general control and protection general and protection without complex wire.

3. Which equipment can be connected to the intelligent port of 100 A?

The intelligent port is multifunction and allows you to attach a Auxiliary electric generator (generator set), Photovoltaic systems of other manufacturers or manage smart charges as heat pumps or load stations.

4. How many inverters Hoymiles Can you manage directly from this footbridge?

The HiBox-100S-G3 Admits direct connection of up 2 inverters Operating with a maximum current of combined input 54.5 a.

5. What other components of the range Hoymiles and inverters I can acquire in Tienda Solar?

In the catalog of Tienda Solar You will find a selection of Inverters solar, Microinverters, inverters hybrid, Inverters Networking and storage batteries like Gel batteries or Inverters AGM.
