Solar panel LONGI Hi-MO X6 72-cell 580W

€144.00
Tax included

Monocrystalline Longi solar panel of 580 Wp (144 split cells)

Monocrystalline photovoltaic module of PERC technology (Passive Enitter Rear Cell) of the Longi Solar brand of 580Wp with a high efficiency of up to 22,5%. This solar panel has a positive power tolerance of 0/+3% that ensures the production of energy throughout its life. Photovoltaic panel of high power and density of solar generation ideal for grid connected or isolated installations with space limitation. Connection of solar panels in series up to 1500V in open circuit

LONGI solar panels offer a 15-year product, manufacturing and material warranty and 25 years of production.

Volume discounts

Quantity Unit price You Save
10 €142.56 Up to €14.40
20 €141.84 Up to €43.20
30 €141.12 Up to €86.40
Quantity

The main advantages of this solar panel are

  • - Solar panel with passivated solar cells back emitter or also called PERC which provides high efficiency (22.5%) compared to conventional solar cells.
  • - Slower power degradation compared to other solar panels thanks to its Low LID technology (Light Induced Degradation) or also called Light Induced Degradation. with a minimum initial degradation.
  • - Solar panel with better performance before situations of partial shading due to its 144 cells of smaller size (72 items).
  • - The split cells mounted on the LONGI 580Wp solar panel provide better performance due to the shorter bus bar length that generates the recombination of electrons
  • - High resistance to PID (Power Induced Degradation) degradation by voltage difference due to its high quality manufacturing process and selection of materials
  • - Reduced formation of micro-cracks in the cells of this Longi photovoltaic panel as they are smaller which favours the production of solar energy throughout its life.
  • - Less power loss of the solar panel due to the low operating current of the LONGI split cells.
  • - Solar panel capable of withstanding high static-snow mechanical loads of up to (5400Pa) and dynamic-wind loads of 2400Pa.
  • - Max module efficiency: 22.5 %
  • - Power Tolerance: 0/+3 %
  • - First year power degradation: < 1.5%
  • - Year 2-25 power degradation: 0.4 %

Features: STC (1000 W/m2; T cell of 25ºC):

Model

LR5-580M-72HTH

Peak power (Wp)

580

Max power tolerance

0/+3%

Voltage at maximum power Vmpp (V)

44,06 V

Maximum power current Ampp (A)

13,17 A

Open circuit voltage (Voc)

52,21 V

Short circuit current (Isc)

14,20 A

Module efficiency (%)

22,5%

# of cells

144 Monocrystalline

Module dimensions

2278 x 1134 x 35 mm

Weight

27,5 kg

Glass

3,2 mm tempered glass

Frame

Anodized aluminum silver color

J-Box

IP68 with 3 bypass diodes

Cables

PV cable 4 mm2

Connectors

MC4 or equivalent

LONGIPERC580M72HTH

Data sheet

Power (W)
500 - 545
Height (cm)
220 - 229.9
Width (cm)
110 - 119.9
Frame
Silver
Short Circuit Current Isc (A)
13 - 13.99

Specific References

Download

Datasheet

Datasheet Longi 580W

Download (2.61MB)
