Advanced BMS Afore for lithium battery ATOM Hvs

Benefits of the Advanced BMS Afore in the ATOM Hvs

As in other high-voltage stable series of Afore, the BMS of the ATOM HVS coordinates the electrical safety of all the stack, not only an isolated module, activating protections against Overvoltage, overcurrent, overtemperature and short circuits In each of the modules connected in series. This electronic management, combined with the Cells LifePo4 grade to, allows the system to reach a life cycle of 6000 cycles and one Design life of 10 years, surpassing technologies with more limited management such as Gel batteries or AGM batteries.

A differential element of this BMS against other ranges Afore is the Low-temperature heating management Included as standard, which allows you to keep the cells within its optimal range of operation even in installations located in cold areas, without the need to hire this function as an additional option. This, along with a Efficiency equal to or greater than 97%, convert to ATOM HVS in a lithium battery especially robust for demanding residential applications, integrating without friction with inverters hybrid Compatible of the brand.

Triple Communication: Bluetooth, WiFi and RS485

The BMS of the ATOM HVS stands out by offering up Three communication protocols (Can / rs485 / WiFi) in addition to Bluetooth For local configuration, a wider combination than other series Afore. This flexibility allows to adapt the system to different installation scenarios: Initial configuration via Bluetooth, stable integration with the inverter by CAN / RS485, and Remote monitoring in real time along with firmware updates Through WiFi, all managed from the manufacturer's mobile application.

Safety and control parameters managed by the BMS

• Active protections: Overvoltage, overcurrent, overtemperature and short circuits
• Managed cell type: LifePo4 grade to
• Maximum controlled load current: 25a
• Maximum controlled discharge current: 50a
• Supervised load temperature range: -10 ° C ~ 55 ° C
• Supervised discharge temperature range: -20 ° C ~ 55 ° C
• Heating at low temperature: Included as standard
• Communication: CAN / RS485 / WIFI / Bluetooth
• Resulting life cycle: 6000 cycles
• System efficiency: ≥97%
• Degree of protection: Ip65
• Anti-corrosion protection class: C4
• Security certification: Cb
• Electromagnetic compatibility: EC
• Transport Certification: Un38.3
• Compatibility: inverters Afore

Frequently Asked Questions (FAQ)

1. What protections offers the BMS of the ATOM Hvs?
Advanced BMS manages protection against Overvoltage, overcurrent, overtemperature and short circuits, in addition to other safety functions oriented to this lithium battery High voltage

2. Does the BMS manage the heating of the battery?
Yes, the ATOM HVS includes Low temperature heating series, integrated within the thermal management of the system, unlike other ranges Afore where this function is optional.

3. How is the system monitored?
Through Bluetooth and WiFi, with additional communication via Can / rs485 towards him inverter, allowing real-time monitoring and firmware updates from the mobile application.

4. What currents do the BMS manage?
The system controls a Maximum load current of 25A and one maximum 50A discharge current, within the safety margins supervised by the BMS.

5. With what inverters the BMS of the ATOM Hvs?
It is compatible with inverters Afore. Check the full range in Inverters solar, and find more technical content in the Blog Tienda Solar.
