Lithium battery Afore ATOM HVS 2.56KWH (1 module)

Benefits of lithium battery Afore ATOM HVS 2.56KWh

The ATOM HVS shares high-voltage stacking philosophy of other ranges Afore, but with a smaller module size (2,56kwh Facing the 5,12kWh from other series), which allows an even thinner capacity adjustment for residential facilities that do not need large power jumps. This granularity is especially useful against lithium batteries of fixed capacity, where any expansion requires to oversize the initial investment.

A differential aspect of this series is the Low temperature heating Included as standard (not optional, as happens in other ranges Afore), which makes it especially suitable for areas with cold winters where ambient temperature could affect the performance of the cells LifePo4 grade to. Combined with Advanced BMS, which protects against overvoltage, overcurrent, overtemperature and short circuits, the system reaches a life cycle of 6000 cycles and one Design life of 10 years, far exceeding solutions based on AGM batteries In terms of longevity and thermal stability.

The compatibility with inverters Afore and the triple communication Can / rs485 / WiFi guarantee a simple integration with inverters hybrid High voltage, maximizing complete system conversion efficiency.

Design for pavement installation

Unlike other series Afore who admit wall mounting, the ATOM HVS is specifically designed for pavement, with an elegant design oriented to residential applications where the aesthetics of the whole is prioritized. This product orientation makes it especially indicated for technical rooms, garages or dedicated spaces where the number of necessary modules can be stacked, complementing facilities that incorporate solar of greater power.

Scalability: from 1 to 8 modules

Starting from this base module 2,56kwh, the manufacturer documents configurations up 8 modules (20,48kWh) In the same stack, allowing to dimension the installation exactly to the ability of each residential project, from small self-conducts to higher energy consumption homes.

Detailed technical characteristics (1 module - 2,56KWh)

Performance specifications:

• Type of cell: LifePo4 grade to
• Configuration: 16s1p
• Nominal voltage: 51.2v
• Nominal capacity: 50ah
• Energy: 2560Wh (2,56KWh)
• Maximum load current: 25a
• Maximum discharge current: 50a
• Maximum discharge power: 2,56kwh
• Lifecycle: 6000 cycles
• Useful life design: 10 years

General Specifications:

• Communication: CAN / RS485 / WIFI
• Efficiency: ≥97%
• Charging temperature range: -10 ° C ~ 55 ° C
• Discharge temperature range: -20 ° C ~ 55 ° C
• Degree of protection: Ip65
• Anti-corrosion protection class: C4
• Heating at low temperature: Included as standard
• Installation: to pavement
• Compatibility inverter: Afore
• Security certification: Cb
• Electromagnetic compatibility: EC
• Transport Certification: Un38.3

Frequently Asked Questions (FAQ)

1. Can I start with 1 single 2.56kwh module and expand after?
Yes. The ATOM HVS is designed to scale in a modular way: you can start with 1 module (2,56KWh) and add modules until completing a stack of 20,48kwh (8 modules), according to the manufacturer.

2. Can it be installed on the wall?
No. According to the manufacturer, the ATOM HVS is designed for pavement, unlike other series Afore They do admit wall mounting.

3. Do you include heating for cold climates?
Yes, this series incorporates Low temperature heating series, a difference with respect to other ranges Afore where this function is optional.

4. How is this lithium battery monitored?
Through Bluetooth and WiFi, with additional communication via Can / rs485 towards him inverter, allowing real-time monitoring and remote updates by mobile application.

5. With what inverters it is compatible ATOM Hvs?
It is compatible with inverters Afore. Check the full range in Inverters solar, and find more technical guides in the Blog Tienda Solar.
