Lithium battery Deye 16kwh | Low voltage (48V) | SE-F16

Benefits of lithium battery Deye 16kwh SE-F16

The lithium battery Deye Is-f16 it is positioned in the market as a reference component thanks to its exceptional energy density in a compact low voltage format (48v /51.2Vdc). Being built with technology cells Lifepo4, this unit entirely eradicates the risks of thermal leakage, offering maximum chemical stability and home safety or the company against other lithium compositions. Unlike traditional storage systems, the Deye 16kwh it stands out for its null initial degradation and its ability to withstand continuous and intense current deliveries without suffering drastic voltage falls.

Your Latell generation smart BMS real-time the critical parameters of the accumulator, applying a passive / active balance cell to cell to ensure minimal degradation over the years. This advanced thermal and electrical management translates into a projected life of more than 6,000 work cycles, backed by a solid product guarantee of 5 years direct manufacturer world leader. To maximize the use of your solar surpluses, you can combine this module with our inverters hybrid of low voltage or consult our full Solar Kits in the official store of Tienda Solar.

Continuity, flexibility and unprecedented scalability

One of the great concerns by expanding a photovoltaic system is the obsolescence of the previous models. With the Deye Is-f16, this barrier disappears: it has been specifically developed to be 100% compatible to work in parallel next to the previous model RW-F16. This allows users to amplify the energy capacity of their previous installation without the need to change the existing equipment or suffer imbalances in the load flow.

In addition to its retroactive compatibility, the system boasts an imposing modular scalability, allowing you to connect up 32 units in parallel. This feature allows you to climb the energy reserve from the 16 kwh initials up to a massive capacity of 512 kWh, covering from demanding nocturnal consumption in single-family homes to complex industrial demands. This versatility is integrated perfectly on structures for solar set on cover that captures the maximum possible production to nourish the battery bank.

Thermal resistance, advanced design and monitoring

Despite hosting a great capacity of 16 kwh, the lithium battery Deye SE-F16 optimizes space with a chassis of 480 x 830 x 235 mm and an approximate weight of 126 kg, Ideal for your location on soil in technical rooms, garages or machine rooms. Its natural cooling system without noisy fans guarantees silent and low-consumption operation, operating in a totally efficient way in an extreme thermal spectrum of -20 ° C A + 55 ° C.

To maintain absolute control of energy flow, the Deye Is-f16 supports local connectivity by protocol Bluetooth and total remote communication through the monitoring application of Deye when connecting to inverter. If you want to learn more about the configuration of low voltage accumulation banks and optimize your system, we invite you to visit the Blog Tienda Solar, where our engineers publish purchase guides, technical details and expert advice for the energy transition.

Detailed technical characteristics

• Cumulative nominal energy: 16 kwh gross.
• Nominal work voltage: 51.2 VDC (Low voltage standard 48V).
• Integrated battery chemistry: Lifepo4 (Iron phosphate and high security lithium).
• Load current / maximum discharge: 150 a continuous (peaks according to configuration).
• Guaranteed useful life: > 6000 cycles 80% depth of discharge (DOD).
• Parallel scalability: Allows you to connect up 32 units in parallel (Up to 512 kWh).
• Expansion compatibility: 100% compatible in parallel with the previous model Deye Rw-f16.
• Integrated communication ports: Can2.0 and Rs485 for multiprotocol integration.
• Physical dimensions of the unit: 480 mm x 830 mm x 235 mm.
• Approximate net weight: 126 kg.
• Operating temperature range: -20 ° C to +55 ° C.
• Degree of protection of the chassis: Ip20 (Efficient natural refrigeration).
• Commercial manufacturer guarantee: 5 years warranty official Deye.

Frequently Asked Questions (FAQ)

1. I already have a battery Deye RW-F16, can I add the new SE-F16 to expand my installation?

Yes, the Deye Is-f16 it is 100% compatible for extensions with the previous model RW-F16. Both batteries can be connected in a direct parallel thanks to its self-networking system, allowing BMS to manage the load and discharge in a joint and balanced way without loss of energy efficiency.

2. How many units of the Deye SE-F16 can I connect in parallel?

This model offers exceptional industrial scalability, allowing to interconnect up 32 units in parallel. With this you can expand storage capacity from the 16 kwh of a single module up to a massive total of 512 kWh, adapting to any growth in the electricity demand of your project.

3. Is this 48V battery compatible with inverters solar of other brands?

Although its maximum synergy is achieved with the range of inverters solar hybrids Deye, SE-F16 uses low voltage industrial standard 48v /51.2Vdc and has open protocols Can2.0 and RS485. This makes it compatible with a great variety of Inverters Networking and programmable market hybrids for lithium accumulators.

4. What maintenance does this accumulator from LiFepo4 require against old technologies?

Maintenance is absolutely null. Being a solid state lithium module sealed with protection Ip20, it does not require electrolyte reviews, water filling or periodic equalization charges. It is a massive technological advantage if you are replacing an old bank Gel batteries or Inverters AGM of lead-acid.

5. Is it possible to monitor the status of the battery and cells from the mobile phone?

Effectively. The serie Is-f16 allows local monitoring via wireless connection Bluetooth and the integral remote follow-up through the official app Deye when the battery is connected to inverter. You can check the percentage of load (SOC), the voltage, the temperature and the health of the cells in real time from anywhere. If you are looking for a minor voltage modular solution or prefer to explore other chemicals, we also have lithium batteries and storage systems of various capabilities in our store.
