Three-phase EV charger module SAJ 11kw CU2-11K-T-1 | Integration Ecosystem HS3

SAJ CU2-11K-T-1: Intelligent load of electric vehicles of 11KW, plug-and-play modular connection and photovoltaic surplus management

Optimizing a solar installation of residential self-consumption requires taking a step beyond the traditional domestic supply, linking the production of plaques with sustainable mobility. The automotive recharge module SAJ EV three-phase charger 11k for HS3 (Engineering reference Cu2-11k-tee 1) It has been developed specifically for coupling within the all-in-one storage tower SAJ, Allowing users to recharge their electric vehicle with energy from kilometer 0.

All-in-one native integration without wiring and optimized load power

The main differential value of the CU2-11K-T-1 charger lies in its modular nature and its architecture connection plug-in without using external cables. . When you fit directly into the structure of the HS3 three-phase integral solution, the module is communicated immediately with the inverter (PCS) and the battery management system (BMS) without complex secondary wiring tasks. . The equipment processes a stable output voltage of 400 VAC with a exit current of 16 A , releasing a continuous recharge power of 11 kW. . Thanks to this technological symbiosis, intelligent load modes can be programmed that prioritize the photovoltaic surplus of the day or the energy previously accumulated in the batteries of high voltage lithium system.

Control of energy flow is monitored directly from the mobile application of the ecosystem SAJ, allowing to balance the critical loads of the house with the consumption of the car. . If your photovoltaic installation requires an enlargement of the generation field to simultaneously cover the journeys of your car and household consumption, we suggest you verify our selection of inverters three-phaseWith multiple MPPT followers.

Integrated compact design of 170 mm, IP65 insulation and robustness to extreme climates

The aesthetic and constructive section of the charger maintains the sophistication of the HS3 industrial series of SAJ. . Presents dimensions of 160 x 695 x 170 mm who respect the ultra flat profile of the tower, achieving a design with a thickness of only 170 mm that is easily integrated into its surroundings indoor. . With a net weight of 9 kg and a chassis with protection index Ip65, The module resists the penetration of powder and water sprayed in any direction. Can operate without alterations under severe weather conditions in a temperature range that goes from -30 ° C to + 50 ° C. To ensure a perfect and secure anchor of the entire modular set of the tower on vertical surfaces or residential garage walls, it is essential to have our structures for and reinforced supports of high mechanical load.

Technical specifications (model SAJ Cu2-11k-tee 1):

Electrical input and output parameters (EV):

• System compatibility: Exclusive for all-in-one three-phase solution SAJ Hs3.

• Nominal output power: 11 kW (11,000 W).

• Nominal AC output voltage: 400 VAC ± 20% (Three-phase network).

• Maximum output current: 16 a.

• Energy consumption on hold (stand-by): Optimized for minimum energy impact.

Physical data, assembly and factor form:

• Dimensions of the module: 160 x 695 x 170 mm (High X wide x background).
• Thickness of the profile: 170 mm (Aligned with the aesthetic design of the HS3 series).
• Net weight of the module: 9 kg.
• Type of electrical connection: Quick modular connector type Plug-in (connected plug-in).
• Fixing screwing: Simplified integration in the tower using the system standard.

Environmental protection and operating ranges:

• Degree Protection: Sealing Ip65.
• Operating temperature Ambiance: -30 ° C up to + 50 ° C.
• Humidity range Supported atmosphere: 5% to 95% without condensation.

Frequently Asked Questions (FAQ)

1. Can I install the car charger SAJ 11k as an independent team in my garage? No, this charger with reference Cu2-11k-tee 1 is designed specifically as a internal expansion module for the all-in-one three-phase residential solution SAJ Hs3. . It does not work autonomously or isolated; It should fit physically and electronically within the modular tower of the system to be able to operate.
2. How is installation and wiring of this EV charger is done inside the HS3 tower? One of the greatest advantages of the ecosystem of SAJ it is your revolutionary plug-in modular design. . 11kw EV charger is placed directly on the blocks of the tower no need to use internal cable hoses or complex connections. . Power and data connectors are automatically coupled by pressing the module, requiring only the perimeter screws to ensure its mechanical fixation.
3. What advantages does an integrated 11KW charger off in front of a traditional wall? Being integrated into the HS3 system brain, the CU2-11K-T-1 charger has direct communication with the production of your solar and the charge status of your lithium batteries. . This allows you to configure advanced strategies through your mobile application, such as loading the vehicle exclusively with the solar surpluses of the day, avoiding consuming expensive energy from the commercial network.
4. Is it safe to install this recharge module on the outside of the house? Yes, it is completely safe. The charger module shares the robust protection engineering of the HS3 series of SAJ, counting on a grade certification Ip65 that guarantees a total seal against rain and dust. . In addition, it supports an extreme temperature range of -30 ° C A + 50 ° C , so you can work in the open in residential areas exposed to sun or winter frost.
