Solar Panel AIKO 600WP 144 CELLS N TYPE
Solar Panel AIKO 600WP 144 CELLS N TYPE

Solar Panel AIKO 600WP 144 CELLS N TYPE

AIKO600NTYPE
€114.95
Tax included

AIKO Solar Panel 600WP (144 CELLS) N TYPE

Monocrystalline photovoltaic module with ABC N-Type technology from AIKO with a high efficiency of up to 24%. The solar panel has a positive power tolerance of 0/3% which ensures energy production throughout its lifetime. The All Back Contact technology, which places all connections at the back of the cell, increases the solar irradiation capture surface and reduces electrode resistance heating losses by about 60%, gives us market-leading efficiency. In addition, the module has an exceptional temperature coefficient of -0.26%/°C, which improves the performance of the installation in hot climates.

AIKO solar panels offer a 15-year product, manufacturing and material warranty and a 30-year linear output warranty.

Quantity Unit price You Save
10 €113.80 €11.50
20 €113.23 €34.49
30 €112.65 €68.97


The main advantages of this solar panel are:

  • - Solar panel with ABC N-Type technology which provides high efficiency (24%) compared to conventional solar cells.
  • - Slower power degradation compared to other solar panels thanks to its Low LID (Light induced Degardataion) technology with a minimal initial degradation in the first year (<1.0%).
  • - Solar panel with better performance in partial shading situations due to its 144 smaller cells.
  • - High resistance to PID (Power Induced Degradation) degradation due to its high quality manufacturing process and material selection.
  • - Less micro-crack formation in the cells of this Aiko PV panel due to the smaller cell size, which favours solar energy production over the lifetime of the panel.
  • - Less power loss from the solar panel due to the low operating current of Aiko's split cells.
  • - Solar panel capable of withstanding high mechanical static-snow loads up to (5400Pa) and dynamic-wind loads up to 2400Pa.
  • - Maximum module efficiency: 24 %.
  • - Power tolerance: 0-3%.
  • - Degradation in the first year: <1%.
  • - Degradation from year 2 to 30: <0.35%.

This solar panel is undoubtedly one of the most efficient on the market for residential and commercial installations with the guarantee of one of the leading manufacturers of solar panels in the world. If you have any doubts or queries, please contact our technical team at info@tienda-solar.es

Characteristics in STC (1000 W/m2; T cell of 25ºC):

Model

AIKO-A600-MAH72Mw

Peak Power (Wp)

600

Tolerance Maximum Power

0/3%

Voltage at maximum power Vmpp (V)

44,68 V

Current at maximum power Ampp (A)

13,43 A

Voltage in open circuit (Voc)

53,99 V

Current in short circuit (Isc)

14,20 A

Eficiency (%)

23,2 %

# of cells

144 Monocells

Dimensions

2278*1134*35mm

Weight

28,2 kg

Cristal

3.2 mm tempered glass

Frame

Anodized aluminum

J-Box

IP68, three bypass diodes

Cables

PV Cable 4 mm2

Conectors

MC4 compatible

Power (W)
600 - 650
Height (cm)
220 - 229.9
Width (cm)
110 - 119.9
Frame
Silver
Short Circuit Current Isc (A)
14 - 14.99
