Fronius Symo 8.2kw Full: Intelligent performance and advanced surplus management

The passage to a photovoltaic system of 8200w Requires high-power components capable of supporting demanding energy flows with total stability. The Symo series of Fronius It complies with these guidelines, protecting internal circuits to short circuits or high working temperatures while impeccating synchronization with your three-phase network.

Ecosystem connected with DataManager and Solarweb Native

Unlike inverters of the Simplified Light Range, the inverters solar Fronius in its edition Full They integrate a state-of-the-art wireless communication package. When wirelessly linked by WiFi or Ethernet cable with the property router, the equipment overturns all generation data to the free portal Fronius Solar.web. This allows you to monitor remotely, transparently and a mm, the actual production of your solar panels And check the autoconsum graphics directly from your smartphone or tablet.

Snapinverter installation and algorithm for shading

On Tienda Solar We prioritize the value of intelligent design. Thanks to patented technology Snapinverter, the inverter Solar is separated into two blocks: A fixed wall bracket where all the electrical wiring of the photovoltaic plates, and the power stage. This radically streamlines assembly and tap any technical maintenance work. Also, for covers suffering from partial shadows due to chimneys, trees or clouds, this equipment incorporates software Dynamic Peak Manager. This algorithm periodically sweeps the power curve to locate the ideal operating point, minimizing the energy losses of the installation assembly.

Technical specifications (Symo 8.2-3-M Full model):

• Nominal output power (AC): 8200 W

• Maximum input power (DC): 16400 W (Superior capacity for optimal field oversizing solar)

• Number of MPPT followers: 2

• Start voltage (DC): 200 V

• Nominal input voltage (DC): 595 V

• Maximum input voltage (DC): 1000 V

• Maximum input current (MPPT1 / MPPT2): 16.0 A / 16.0 A

• Short circuit current (MPPT1 / MPPT2): 24.0 A / 24.0 A

• Nominal output current (AC): 11.8 a

• Network output voltage: Three-phase (380V / 400V / 415V)

• Degree of environmental protection: IP65 (suitable for assembly both outdoors and indoors)

• Connectivity included: DataManager, WLAN, Ethernet, Modbus TCP / RTU SunSpec interfaces and Fronius Solar API

• Refrigeration method: Smart forced ventilation (Active Cooling)

• Net weight of the team: 21.9 kg

Frequently Asked Questions (FAQ)

1. What does the Symo 8.2kw "Full" model add regard to the "Light" range? The inverter solar Full Serial account with the DataManager communications card. Thanks to it you have a connection by WiFi and Native Ethernet to link your installation of Solar Places with the mobile monitoring application of Fronius No need to buy additional components.
2. Does this admit inverter Solar 8.2kw Direct link of lithium batteries? The inverters solar series Fronius Standard Symo are designed exclusively for direct network connection modality and are not supported natively with lithium batteries. If you want a hybrid system that combines storage and three-phase generation, we recommend that you consult our specific section of energy storage.
3. How does the zero injection system work work Fronius? If you do not have the permission of poured or prefer not to export power to the network, the inverter automatically reduces the production of your solar In real time to strictly cover the instantaneous consumption of your home or trade, guaranteeing a totally null discharge.
4. What benefit does the Active Cooling contribute to passive cooling? The system Active Cooling Actively extract the internal heat of transistors by forced ventilation. This prevents performance losses due to high temperatures (derating) and substantially lengthens the useful life of these inverters solar, especially in hot climates.
