BMS Pylontech SC1000-100S - Controller Pylontech for PowerCube-H1

Benefits of the BMS Pylontech Sc1000-100s

The BMS SC1000-100S is designed for facilities high voltage that require managing large capacity racks, allowing control up 15 H48050 Battery Modules In the same PowerCube-H1 system. Your Smart loading model automatically optimizes loading and unloading cycles, contributing to a lifespan higher than 15 years In the set of managed batteries.

With a range of Working voltage of 200 to 1000 VDC, this controller is indicated for larger-scale and industrial projects - where scalability and precise management of each module are needed. It integrates perfectly with lithium batteries high capacity, ensuring a Isolation and protection robust electric and a Active cell rolling That homogenizes the performance between all rack modules, avoiding decompensations that shorten the life of the cells.

Its bass Own consumption of 8W Reduces system losses, while communication Modbus RTU / Can guarantees a fluid integration with Inverters solar Latest generation, allowing the state of charge (SOH) and health (SOH) at the installation at all times.

Scalability for great capacity projects

Unlike lower voltage controllers, the SC1000-100S allows dimensioning large-scale storage systems without losing energy efficiency, ideal to combine it with solar panels High production in commercial and industrial self-consumption facilities. If your project also requires a robust assembly, in the store you will find solar adapted to any type of cover or soil.

Compatibility with other installation equipment

Thanks to its standard communication, the SC1000-100S can be integrated so much with Inverters Networking as with configurations that include Microinverters, facilitating high-performance hybrid projects. If you have doubts about the sizing of your system, see the Blog Tienda Solar, where you will find technical guides developed by our experts.

Detailed technical characteristics

• Related product: Powercube-h1
• Driver working voltage: 200-1000 VDC
• System operating voltage: 200-1000 VDC
• Maximum loading / unloading current: 100a
• Own consumption: 8w
• Dimensions (an × prof × al): 442 × 390 × 132 mm
• Weight: 8.5 kg
• Communication: Modbus RTU / Can
• Degree of protection: Ip20
• Operating life: 15+ years
• Operating temperature: -20 ° C to 65 ° C
• Storage temperature: -40 ° C to 80 ° C
• Compatible battery module: H48050
• Rack configuration: between 5 and 15 modules

Protection and alarm functions:

• End of charge / download
• Upload
• Cargo / unloading overcurrent
• High / Low Temperature
• Operating record
• Current monitoring, tension, temperature, SOC and SOH

Management and monitoring functions:

• Cell rolling
• Smart loading model
• Capacity retention calculation
• Isolation and protection
• Alarm management

Frequently Asked Questions (FAQ)

1. With what batteries is the BMS SC1000-100S compatible?
The controller Sc1000-100s It is compatible with battery modules Pylontech H48050, within the high voltage system Powercube-h1.

2. How many battery modules can I connect to this BMS?
The PowerCube-H1 system admits between 5 and 15 modules Battery H48050, depending on the energy capacity required by your installation.

3. How is BMS difference SC500-100S?
The SC1000-100S works in a higher voltage range (200-1000 VDC versus 60-600 VDC), which makes it suitable for higher capacity and voltage facilities, while the SC500-100S is designed for low-scale PowerCube-X1 systems.

4. What kind of communication do you use to integrate with the inverter?
Use protocols Modbus RTU and Can, guaranteeing a stable and compatible communication with the majority of inverters hybrid of the current market.

5. What protections incorporates this BMS?
Includes protection against Overloads, loading / unloading overcurrents, high and low temperatures, along with a system of electrical insulation and continuous registration of all operating events.

6. What is the estimated useful life of the SC1000-100S controller?
The manufacturer indicates a useful life of operation over 15 years, in line with the durability of the Gel batteries and high-voltage lithium that manages.
