Solar Panel Aiko 520W Neostar 2P60 A-Mah60MW MC4 Black 1500V

Benefits of the Solar Panel Aiko Neostar 2P60 520W

Panel Aiko Neostar 2P60 A520-Mah60MW highlights in front of other conventional modules thanks to its ABC Technology (All Back Contact), that transfers all the electrical connection to the back face of the cell. This not only improves the aesthetics of the panel (without visible bus lines), but also optimizes the uptake of light and reduces the losses per partial shading, a critical factor in rooftops with obstacles such as chimneys or antennas.

In terms of thermal performance, its Pmax temperature coefficient is only -0.26% / ° C, one of the lowest values in the sector, which translates into a Lower loss of power in warm climates Like the Mediterranean. This is added an excellent Resistance to degradation induced by potential (PID) and microfisters, thanks to its robust cell structure and its high quality encapsulation.

The manufacturer supports this module with a Product guarantee of 15 years (expandable to 25) and one 30-year linear power guarantee, with Munich Re as a coverage partner, offering long-term tranquility both installers and individuals.

If you are designing a complete installation, in Tienda Solar You will find everything you need: from these solar high efficiency up inverters hybrid compatible and solar adapted to any type of cover.

For what type of installation is this panel recommended?

Thanks to his Maximum system tension of DC1500V and its compact format 1954 x 1134 x 30 mm, Aiko Neostar 2P60 520W is a versatile solution, suitable for small residential self-consumption facilities and for large-scale commercial plants. Their weight of 23.1 kg and black anodized aluminum reinforced frame allow to resist Front static loads up to 5,400 pa and subsequent 2,400 pa, as well as hail impacts 40 mm to 23 m / s, which makes it especially suitable for areas with adverse climatology.

If your project requires energy storage, this panel perfectly combines lithium batteries to maximize self-consumption, or with Gel batteries In isolated facilities of lower cyclical requirement.

Compatibility with injection and self-consumption systems

This module is fully compatible with network connection configurations thanks to its Connector MC4-EVO2A and IP68 connection box with 3 bypass diodes, which minimize losses by partial shading in the string. For facilities that seek to inject surpluses to the electricity network, we recommend reviewing our range of Inverters Networking, while for panel-level optimization systems, microinverters They are an alternative to consider according to the design of the project.

Detailed technical characteristics

Electrical data (STC: AM1.5, 1000W / m², 25 ° C):

• Maximum nominal power (PMAX): 520 W
• Efficiency of the module: 23,5%
• Open circuit voltage (VOC): 45.42 V
• Tension at the maximum power point (VMP): 38.30 V
• Short circuit current (ISC): 14.29
• Current at the point of maximum power (imp): 13.58
• Power tolerance: 0 ~ + 3%

Electrical data (noct: AM1.5, 800W / m², 20 ° C, 1m / s):

• Power (PMAX): 394 W
• VOC: 43.09 V
• Vmp: 36.34 V
• ISC: 11.54
• Print: 10.86

Temperature coefficients:

• ISC Temperature Coefficient: + 0,05% / ° C.
• VOC temperature coefficient: -0,22% / ° C.
• PMAX temperature coefficient: -0,26% / ° C.

Product Specifications:

• Type of Cell: N-Type ABC
• Number of cells: 120 (6 × 20)
• FRONT GLASS: 3.2 mm temperate
• Backsheet: High resistance to the weather
• Setting: Black anodized aluminum
• Cable: 4 mm² (IEC) / 12 AWG (UL), ± 1200 mm
• Connection box: IP68, 3 BYPASS diodes
• Connector: Mc4-evo2a
• Weight: 23.1 kg ± 3%
• Dimensions: 1954 × 1134 × 30 mm

Installation data:

• Operating temperature: -40 ° C A + 70 ° C
• Maximum series fuse: 25 a
• Protection class: Class II
• VOC tolerance and ISC: ± 3%
• Maximum system tension: DC 1500 V
• Maximum static load: Front 5,400 PA / Back 2,400 Pa
• Resistance to hail: 40 mm in diameter to 23 m / s
• Fire Classification: IEC Class C

Guarantees and certifications:

• Product guarantee: 15 years (expandable to 25 years)
• Linear power guarantee: 30 years
• First year degradation: ≤1%
• Annual degradation (year 2-30): ≤0,35%
• Guaranteed performance (year 30): 88,85%
• Certifications: IEC 61215, IEC 61730, EC, ISO 9001: 2015, ISO 14001: 2015, ISO 45001: 2018
• Warranty Partner: Munich re
• Acknowledgments: Tier 1 Bloombergnef, Red Dot Winner 2023

Frequently Asked Questions (FAQ)

1. What is the difference to N-Type ABC technology of the conventional percee cells?

Technology ABC (All Back Contact) Transfer all the electrical connection to the back of the cell, eliminating visible metal grids on the front face. This reduces losses per shader of the connections themselves and improves the uptake of light, which translates into a Upper efficiency of 23.5% In front of the market average.

2. Is this panel compatible with facilities of more than 1000V?

Yes. The Aiko Neostar 2P60 panel admits a Maximum system tension of DC1500V, which allows you to design longer strings, reduce the number of combiners needed and optimize wiring in larger installations.

3. What kind of inverter Do I need for this panel?

Being a standard network connection module, it is compatible with both Inverters solar centralized as with Microinverters Individuals, depending on the configuration of shadows and the design of your installation.

4. How long is the panel power degrades over the years?

The manufacturer guarantees a Maximum degradation of 1% in the first year and of ≤0.35% per year from the second to the thirtieth year, reaching a 88.85% guaranteed performance at the end of the year 30, backed by a 30-year linear power guarantee.

5. Is this panel suitable for climates with hail or strong winds?

Yes. He has overcome the Hail test with impacts of 40 mm diameter to 23 m / s, and supports Front static loads up to 5,400 pa and subsequent 2,400 PA, complying with certification standards IEC 61215 and IEC 61730.

6. What connector uses and is compatible with other manufacturers?

Use the connector Mc4-evo2a, compatible with the usual MC4 standards of the sector, which facilitates its integration with wiring, inverters hybrid and existing assembly structures.
