Solar inverter charger Axpert VM IV 5600-48V
Solar inverter charger Axpert VM IV 5600-48V

Inverter Solar charger Axpert VM IV 5600-48V

AXVMIV560048
€484.00
Tax included

Inverter Solar charger for isolated 5600W to 48V isolation installations to be able to connect the corresponding voltage solar battery bench (48V). The Axpert VM IV 5.6K has a single MPPT (maximum power tracking point) and provides a yield of 93.0%. The maximum solar regulator input current is 120A.

The AXPERT VM IV 5600W 48V integrates the MPPT loading controller and can be configured with up to 6,000 WP. This model unlike the Axpert 3K does have the start-up feature of generators for hybrid solar installations.

This inverter 5,6KW Axpert VM IV (KVA) charger offers a guarantee of 2 years of product and CE certificate.



This model incorporates a 4,3 ", WiFi, USB color touch screen, stores the incidents, system to maximize the useful life of batteries and an anti-dust kit.

The inverter solar Axpert VM IV 5600W-48V as the rest of the family stands out in addition to its price for the following characteristics:

  • - Inverter isolated pure sine wave wave of great efficiency
  • - Output power factor of 1 which involve 5,6KW of real power
  • - MPPT loading regulator integrated in the inverter solar
  • - Wide range of input voltage selection of the inverter solar 90-280V)
  • - Wide range of selection of entry current of the inverter solar for battery charge up to 120A
  • - Configurable AC / Solar Entrance through the LCD screen
  • - In this case the AXPERT VM IV 5600-48V has auto-land for diesel generator or hybrid installation
  • - Overvoltage and short circuit protections in the inverter solar
  • - Option for coupling remote control of the inverter charger

The inverter- Axpert Farger VM IV 5600W-48V is a very economical option for demanding customers who want to own a reliable and smooth quality product in the operation of its installation.  For any questions, consult with us in [email protected]

Technical characteristics

Model

Axpert VM IV 5600W-48V

Nominal power

5600va / 5600w

Entrance voltage

230vac

Assigned network frequency / frequency range

50hz / 60hz

Output voltage AC

230VAC +/- 5%

Maximum power peak transient

11200va

Efficiency peak

93%

Waveform

Pure sine

Battery tension

48vdc

Load floating tension

54vdc

Overload protection

63vdc

Maximum power Solar PV

6000wp

MPTT range in operating voltage

120VDC - 450VDC

Maximum tension of circuit open by String

500vdc

Maximum solar current

120a

Maximum AC current

100a
Power (kW)
3 - 5.9
Phase Type
Single phase
Max Current Input (A)
12 - 12.99
Compatibility list
Dyness BX51100
Dyness Power Box
Pylontech Force L2
Pylontech US2000C / US3000C / US5000
Pylontech US3000C
Pylontech US5000 / Force L2
Turbo Energy (Slim)
