Lithium battery Afore ATOM HS 5.12KWh (1 module)

Benefits of lithium battery Afore ATOM HS 5.12KWh

Unlike other lithium batteries of low voltage, the ATOM HS is committed to an architecture of High stacking stress, where each added module increases the total voltage of the system instead of only the capacity in amperes-hour. This translates into greater conversion efficiency and lower current losses in higher power, especially relevant installations when combined with inverters hybrid High voltage designed to take advantage of these electrical advantages.

The cells LifePo4 grade to Employed in this module provide superior stability and safety against other chemicals in the market, allowing reaching a Life cycle of up to 6000 cycles to 0.5c and one Design life of 10 years. The Advanced BMS, with protection against overvoltage, overcurrent, overtemperature and short circuits, works in a coordinated way among all the stack modules to ensure safe operation even in high power configurations, something that technologies such as the AGM batteries They can not offer at the same level.

A particularly relevant data for installers is that Each module is able to supply a maximum power of up to 40kw, which allows dimensioning installations of high energy demand with very few modules, optimizing the space occupied against other solutions of higher volume.

Advanced monitoring: Bluetooth and integrated Wifi

The ATOM HS incorporates Bluetooth and integrated Wifi Series for real-time monitoring and remote updates of the system through the manufacturer's mobile application, without the need for additional communication modules. This dual connectivity facilitates both the initial configuration in local via Bluetooth and continuous remote monitor via WiFi, allowing the user or installer to consult the charging status, temperature and system performance from any location. Communication with the inverter It is carried out by protocol Can / WiFi, ensuring a fluid integration with the systems Afore compatible.

Scalability: from 1 to 8 modules in the same stack

Starting from this base module 5,12kwh, the manufacturer documents configurations up 8 modules (40,96kWh) In the same stack, allowing installers to size the exact power that each project needs. In addition, the system admits 5 units in parallel, further multiplying the total capacity available for residential facilities or small commercial facilities that require greater energy autonomy next to their solar.

Detailed technical characteristics (1 module - 5,12KWh)

Performance specifications:

• Type of battery: LifePo4 grade to
• Modules: 1
• Nominal capacity: 100ah
• Energy: 5120Wh (5,12KWh)
• Nominal voltage: 51.2v
• Operating voltage range: 45.6V ~ 57.6V
• Standard load current: 50a
• Maximum load current: 100a
• Standard discharge current: 50a
• Maximum continuous discharge current: 100a
• Load voltage limit: 45.6v
• Recommended discharge depth (DOD): 80%
• Lifecycle: 6000 cycles to 0.5c
• Useful life design: 10 years
• Maximum power per module: up to 40kw

General Specifications:

• Communication: CAN / WIFI / Bluetooth
• Efficiency: up to 97%
• Maximum of units in parallel: ≤5 units
• Discharge temperature range: -10 ° C ~ 50 ° C
• Charging temperature range: 0 ° C ~ 45 ° C
• Degree of protection: Ip65
• Degree of protection against corrosion: C4
• Auxiliary heating function: Optional
• Optional dimensions (an x PR): 590 x 414mm
• Certifications: CB-IEC62619 / EC / UN38.3
• Compatibility inverter: Afore

Frequently Asked Questions (FAQ)

1. Can I start with 1 single 5.12kwh module and expand after?
Yes. The ATOM HS is designed to climb modularly: you can start with 1 module (5,12KWh) and add modules until completing a stack of 40,96kwh (8 modules), according to the manufacturer.

2. What power can each module deliver?
According to the manufacturer, Each battery module is able to supply a maximum power of up to 40kw, which allows dimensioning high demand facilities with few modules.

3. How is this lithium battery monitored?
Through Bluetooth and integrated Wifi, which allow local configuration and remote monitoring in real time through the manufacturer's mobile application, including firmware updates.

4. With what inverters it is compatible ATOM Pm?
It is compatible with inverters Afore by communication Can / WiFi. You can check the full range in Inverters solar To complete your installation.

5. Is it suitable for outdoor?
Yes, thanks to your IP65 protection and corrosion resistance C4, This lithium battery can be installed indoors or exterior. Consult more technical content in the Blog Tienda Solar, with purchase guides and tips prepared by experts.
