Battery base for soil SAJ B2-HV Base | HS2 series structural support

SAJ B2-HV Base: floor support platform for high voltage towers, anti-roll engineering and accurate leveling for lithium modules

Display a residential energy storage system in all-in-one compact tower format requires not only an advanced electronic management, but also a robust mechanical support infrastructure. The platform SAJ BU2 HV Battery Base it provides the indispensable physical foundation on which the module is segured safely hybrid Inverter and the Lithium Blocks Ferrophosphate of the HS2 range, isolating the set of direct contact with pavement moisture.

High-load stability, adjustable legs and uniform weight distribution

The main differential factor of this constructive base lies in its ability to support heavy loads continuously. A complete tower of the HS2 series configured to its maximum capacity can be widely overcame the 125 kg of static mass when stacking the storage and control modules. Part B2-HV base uniformly distributes all this center of gravity towards the support points of the soil, avoiding structural tensions on the walls of housing. Incorporates into its lower section a game of micrometric thread bulldozers, which allow the installer to regulate height independently to compensate for water falls or common superficial imperfections in garages concrete floors, basements or residential patios. If you are planning a large exterior photovoltaic installation combined with this accumulation tower, we invite you to examine our solutions of structures for aluminum with reinforced anchors.

The base maintains a textured surface that maximizes the friction coefficient, fixing the first lithium accumulator block through a mechanical guide channel that prevents lateral displacements or vibrations. To ensure that your system maintains an optimal and continuous recharge supply towards the modules located on this base, we suggest you review our specialized menu of batteries and high efficiency sensors.

IP65 IP65 Shield, Integrated Profile Design and Security Fixation

In tune with the demanding standards of isolation of the signature SAJ, this floor base has a complete approval of environmental protection Ip65. . Its coatings and sealing joints are prepared to withstand rigorous weather conditions in the open, resisting clean water splash, torrential rainfall and environments with relative humidity of up to 100% without suffering Degradation by early oxidation. . Its physical dimensions 626 mm width and 365 mm depth respect the millimeter the geometric footprint of the BU2 chassis, achieving a clean monolithic aesthetic that hides the anchors and enhances the visual sobriety of the house. If your domestic project requires transitioning in the future to commercial configurations or you want to evaluate hybrid technologies of superior power, you can inform you in our catalog of inverters hybrid single-phase and three-phase.

Technical specifications (model SAJ B2-HV Base):

Compatibility and structural parameters:

• Ecosystem compatibility: Designed exclusively for the foundation of the Tower all-in-one SAJ Hs2.

• Main application: Bottom base support for stacking of battery modules Bu2-5.0-hv1 / 5.

• Static load capacity: Optimized to securely support up to 4 storage blocks and 1 inverter.

• Type of assembly supported: Direct fixing on floor surfaces.

Dimensions, plant dimensions and form factor:

• Width of the platform: 626 mm (Perfect alignment with the series of batteries HS2).
• Depth of the platform: 365 mm.
• Leveling system: Lower threaded legs with independent vertical adjustment range.
• Outside finish: Metallic paint with industrial anticorrosive powder coating.

Environmental protection and resistance:

• Degree of structural isolation: Sealing certification Ip65 (Apt for aperture).

• Associated refrigeration method: Favors free air circulation by natural convection under the tower.

• Humidity resistance: Immune to saturated water environments or floor condensation.

Frequently Asked Questions (FAQ)

1. Is it strictly mandatory to use the base of soil B2-HV Base to mount the batteries SAJ Hs2? Yes, it is totally indispensable and mandatory for the facilities that are supported on the ground. . This base acts as the structural foundation of the entire all-in-one tower, guaranteeing that the massive weight of the LifePO4 batteries is distributed correctly. In addition, it raises a few centimeters the first storage module, avoiding the lower electrical connectors to come into direct contact with humidity, dirt or possible filtrations of pavement water.
2. How do they help adjustable legs of this base if the floor of my garage is inclined? The floors of the garages and terraces usually have water evacuation earrings or irregular rugged surfaces. The base of SAJ it incorporates high-strength threaded mechanical legs that can be adjusted individually in height. This allows the installer to level the platform perfectly by means of a bubble level before stacking the heavy battery modules, ensuring that the tower is completely vertical and free of risks of tilt or rollover.
3. Is the base protruding or alters the aesthetic design of the storage tower? No, at all. The soil base has been designed by the Department of Engineering SAJ sharing exactly the same aesthetic line of the HS2 series. . It has the same width of 626 mm and depth of 365 mm that the battery modules. . When being perfectly integrated and enrassed under the first block of lithium, it maintains the minimalist and clean visual aspect of compact tower without wires on the wall.
4. Can you place this base to the weather in an outer patio or garden? Yes, it is perfectly apt. Just like the hybrid Inverter and the storage cells of the ecosystem, the base has a grade environmental protection certification Ip65. . Its metallic chassis has been subjected to industrial treatments with special paintings that prevent corrosion and oxidation caused by constant rain, winter frosts or relative high humidity environments.
