Battery module BYD Battery-Box HVM + 2.76 KWh | High performance modular energy

BYD HVM + 2.76: The base of a smart storage system

The module HVM + 2.76 KWh It represents the evolution of domestic energy storage. BYD, a world leader in LFP technology, has designed this module to offer not only capacity, but a management intelligence that optimizes each loading and unloading cycle.

Scalability and flexibility without limits

On Tienda Solar We value adaptability. An HVM + system begins with a minimum of 3 modules (8.3 kWh) and can grow up to 8 modules (22.1 kWh) per tower. Thanks to its modular design with Patented internal plug connection, Expanding the capacity of your system is as simple as adding a new module on the existing, regardless of the current SOC (load state). This allows your investment to grow to the rhythm of your energy needs.

Extreme safety and performance

Security is the priority of BYD. Chemistry Lifepo4 It guarantees exceptional thermal stability and a long service life. In addition, the HVM + module has a Integrated equilibrium optimizer It ensures that all cells work harmonica, maximizing round-trip efficiency (≥95%). This module is the ideal companion for your lithium batteries High voltage, allowing perfect integration with the main single-phase and three-phase investors in the market, guaranteeing that your photovoltaic plant render the highest level.

Technical specifications (of the individual module):

• Model Model: HVM + (2,76 kWh)

• Technology: Lithium and iron phosphate (LifePO4)

• Nominal capacity: 2,76 kWh

• Nominal voltage: 51.2 V

• Maximum loading / unloading current: 50 a

• Dimensions (module): 585 x 298 x 233 mm (approx.)

• Weight: 41.4 kg

• Degree of protection: IP55 (suitable for indoor and exterior)

• Efficiency: ≥95%

• Communication: CAN / RS485

• Certifications: VDE2510-50 / IEC62619 / CE / UN38.3

• Warranty: 10 years (direct from the manufacturer)

Frequently Asked Questions (FAQ)

1. Can I use a single HVM + 2.76 kWh module? No, the Battery-Box HVM + systems require a minimum of 3 modules (8,28 kWh) to run correctly due to system voltage requirements. You can see the full configurations in our Solar kits.
2. Is it difficult to expand the battery in the future? At all The "Plug-and-Play" design allows you to add additional modules without the need for external wiring between them. In addition, HVM + technology allows expanding capacity at any time of system life.
3. Where is it better to install these batteries? Thanks to its certification Ip55, they can be installed both indoors and outdoor protected, supporting a temperature range of -10ºC A + 50ºC.
4. What maintenance do they require? Maintenance is practically null. The system includes Remote diagnosis and OTA updates (OVER-THE-AIR), which allows the software to remain automatically optimized without user intervention.
