Lithium Battery V-TAC 9.60KWH - VT-48200B Rack 48V

Battery Benefits V-TAC VT-48200B

The V-TAC VT-48200B is positioned in Tienda Solar As one of the most robust options for technical and professional environments looking for a forceful energy reserve in format rack. With 9,60kwh of nominal capacity, this battery is capable of sustaining high consumption, maximizing the use of your solar panels Or Telecom-type backup facilities.

LIFEPO4 technology and performance

This model uses cells LFP (LifePO4) High quality, recognized by their thermal stability against other lithium chemists. Your Freight and discharge current of up to 100A Allows high energy efficiency, backed by a design that integrates Multiple protection methods based on patented technology.

Smart BMS with advanced functions

The BMS (Battery Management System) integrated incorporates a smart anti-theft solution and one Optional LCD screen For local monitoring of battery status. Your compatibility with protocols Modbus, CAN and SNMP (V2 / V3 optional) It allows fluid integration with remote monitoring systems, typical of professional and telecommunications environments, as well as with inverters hybrid Compatible with these standards.

Rack format for professional facilities

Dimensions 445 x 244 x 500 mm and a weight of 81 kg, this model is designed for installation in Racks or technical cabinets, optimizing the space in data centers, telecommunications rooms or commercial facilities that require an orderly and modular deployment next to others lithium batteries of the range

Thermal range and security

Its working temperature range -0 ° C to 60 ° C on load and -20 ° C at 60 ° C in download- together with a relative humidity admitted up to the 95%, it makes it suitable for installations in variable environments. If you have doubts about how to integrate it into your system, see the guides of the Blog Tienda Solar.

Detailed technical characteristics

• Model: Vt-48200b
• SKU: 11523 (EAN 3800157693578)
• Type of battery: LIFEPO4 (LFP)
• Nominal capacity: 200ah (@ 0.2c, 25 ° C)
• Nominal voltage: 48,0v
• Nominal load voltage: 54,0v
• Discharge tension: 40,5v
• Maximum continuous load current: 100a (@ 25 ° C.)
• Maximum continuous discharge current: 100a (@ 25 ° C.)
• Charging temperature: 0 ° C to 60 ° C
• Discharge temperature: -20 ° C at 60 ° C
• Relative humidity admitted: ≤95% RH
• Degree of protection: Ip20
• Communication: Modbus / Can / SNMP V2 / SNMP V3 (optional)
• Additional BMS functions: Intelligent anti-theft protection, LCD screen (optional)
• Dimensions (an × prof × al): 445 × 244 × 500 mm
• Weight: 81 kg approx.
• Assembly: Rack (Format 19 inches)
• Certifications: CE, RoHS
• Warranty: 5 years

Frequently Asked Questions (FAQ)

1. Is it compatible with my inverter If it does not appear on the list?
The VT-48200B uses standard industry protocols (Modbus, Can and Snmp). If you hybrid Inverter It supports 48V lithium batteries with one of these protocols, it is very likely that it is compatible. Consult us in Tienda Solar To confirm it.

2. Can I mix it with other V-TAC models?
To guarantee the stability of the system and the correct load rolling, we recommend connecting only only modules of the same model Vt-48200b.

3. What is the difference between this model and the V-TAC wall mounting versions?
The VT-48200B is designed specifically for Rack assembly (Format 19 "), unlike other range models designed for wall or soil, which makes it especially suitable for technical rooms, telecommunications racks or commercial facilities.

4. What protection includes the BMS of this model?
Incorporates Multiple patented protection methods, in addition to a smart anti-theft solution, protecting both the electrical integrity of the system and the physical safety of the equipment.

5. Can I monitor the battery status locally?
Yes, the model admits a Optional LCD screen To consult parameters such as voltage, current and temperature directly from the computer, without the need for remote connection.

6. What guarantee does the VT-48200B have?
It has a guarantee of 5 years, backed by certifications CE and ROHS that prove compliance with European quality and safety standards.
