Inverter Solar Fronius Symo Gen24 6.0 Plus | Hybrid Inverter Three-phase with advanced backup

Fronius Symo Gen24 6.0 Plus: Efficient performance and autonomy in three-phase networks

Maximize the performance of a photovoltaic installation in a three-phase network requires a core inverter Able to manage symmetrically and intelligently multiple power flows. The hybrid Inverter Fronius Symo Gen24 6.0 Plus assume this responsibility with maximum Austrian precision, transforming the DCT will solar To cover in real time the demands of your home or small business, achieving a drastic savings on the light invoice under CE marking.

Emergency energy without interruptions: PV Point and Full BackUp

The great differential advantage of the platform Gen24 plus compared to inverters of traditional three-phase network lies at its high level of resilience against the public distribution network:

• PV Point: A single-phase emergency outlet built into the chassis itself that is activated automatically during radiation hours. It provides up to 3 kW of power to feed basic consumption (routers, refrigerators or lighting systems), regardless of whether there is a battery connected or not.

• Full BackUp: By complementing the 6kw of equipment power with an external switching system and lithium batteries, the inverter Take full control of installation in milliseconds. In this way, it feeds all the three-phase charges of the property so that the activity continues transparently during the blackout.

Anti-shadow technology avant-garde and stance architecture

On Tienda Solar We select components that simplify the installation and guarantee an extensive useful life. The Symo Gen24 range evolves with respect to the old Snapinverter ecosystem by introducing a more compact, light and sealed chassis with IP66 degree of protection. Thanks to his 2 independent MPPT followers, it manages with solvency roofs with different orientations or earrings. In the presence of partial shadows caused by chimneys or wooded environments, its dynamic algorithm Dynamic Peak Manager continuously monitor the I-V curve to ensure your photovoltaic plates Always render to the maximum capacity.

Technical specifications (model Symo Gen24 6.0 Plus):

• Nominal output power (AC): 6000 W (6 kW)

• Maximum input power (DC): 9000 W (Excellent margin for the oversizing solar)

• Number of MPPT followers: 2

• Maximum efficiency Inverter: 97,7%

• Compatible batteries: High voltage systems BYD Battery-Box Premium HVS / HVM

• Battery input voltage range: 150 V - 500 V

• Network synchronization: Three-phase (380V / 400V)

• Degree of environmental protection: IP66 (maximum resistance against dust and water for outdoor or interior installations)

• Integrated connectivity: WLAN (WiFi), Ethernet (LAN), 2x RS485 (Modbus RTU), digital tickets / outputs for series loading control

• Thermal management of electronics: Intelligent forced ventilation (Active Cooling)

• Dimensions of the team: 53.0 x 47.4 x 16.5 cm

• Net weight of Inverter: 16.5 kg

Frequently Asked Questions (FAQ)

1. Can you use the Fronius Symo Gen24 6.0 Plus as inverter of classic network without battery? Yes, perfectly. The team can initially work conventional injecting the production to the network. Thanks to its design Battery Ready, it is completely prepared for you to incorporate a lithium battery In a second phase directly, without having to add chargers or change the installation.
2. What brands and models of lithium batteries are compatible with this 6000W model? The series of inverters Hybrids Gen24 Plus Three-phase is approved exclusively to work in combination with the High voltage lithium batteries manufacturer BYD, specifically with the series BYD Battery-Box Premium HVS and HVM. It does not support low voltage accumulators (48V).
3. Why the Active Cooling system extends the useful life of this hybrid Inverter? The conversion of continuous to three-phase energy together with the simultaneous management of the battery charging cycles generate internal heat. The intelligent active ventilation system forced by improving this temperature, avoiding potency losses due to overheating (derating) and protecting the internal components against premature wear.
4. What is needed to configure the zero injection system? To reduce the power of the inverter and prevent the photovoltaic surplus from turning to the public electricity network, the equipment needs to communicate with the official meter Fronius Smart Meter (available separately), in charge of reading the flows at the border point of the domestic network.
