Inverter Solar Fronius Symo Gen24 8.0 Plus | Hybrid Inverter Three-phase with advanced backup

Fronius Symo Gen24 8.0 Plus: The intelligent energy core for three-phase networks

Ensuring the profitability of a modern photovoltaic installation in three-phase networks with constant demands requires a versatile and accurate electronics. The hybrid Inverter Fronius Symo Gen24 8.0 Plus assume this responsibility with total solvency, efficiently transforming the continuous current of your solar To simultaneously supply the three phases of your home or small business, drastically reducing dependence on conventional electrical network under CE marking.

Continuous supply guarantee: PV Point and Full BackUp Three-phase

Unlike inverters of traditional network, the platform Gen24 plus It stands out for its capacity for resilience against public network by two electrical backup modalities:

• PV Point: A factory integrated emergency power outlet that is activated automatically during sunlights before a blackout, offering up to 3 kW of single-phase power for essential consumption, operate or not a battery at that time.

• Full BackUp: By combining the 8kw of the power of the inverter with an external switching system and lithium batteries, the team is capable of feeding all the three-phase charges of the installation in milliseconds, making the light cuts go completely unnoticed.

Efficiency Facing Shadows and Vanguard Architecture

On Tienda Solar We prioritize robust solutions that simplify technical maintenance. The Symo Gen24 range leaves behind the old Snapinverter design to adopt a more compact and sealed chassis with IP66 protection degree and fast closing screws. Their 2 independent MPPT followers They allow designing Strings of photovoltaic plates in roofs with varied orientations or asymmetric earrings. Also, if there are partial shades due to trees, adjoining ships or chimneys, the native algorithm Dynamic Peak Manager Constantly analyze the power curve to ensure that the system always works at its point of maximum performance.

Technical specifications (model Symo Gen24 8.0 Plus):

• Nominal output power (AC): 8000 W (8 kW)

• Maximum input power (DC): 12000 W (excellent tolerance to the oversizing solar)

• Number of MPPT followers: 2

• Maximum efficiency Inverter: 97,8%

• Compatible batteries: High voltage systems BYD Battery-Box Premium HVS / HVM

• Battery input voltage range: 150 V - 500 V

• Network synchronization: Three-phase (380V / 400V)

• Degree of environmental protection: IP66 (maximum resistance to dust and water for indoor or exterior installations)

• Serial connectivity: WLAN (WiFi), Ethernet (LAN), 2x RS485 (Modbus RTU), configurable digital inputs / outputs

• Thermal management: Intelligent forced ventilation (Active Cooling)

• Dimensions of the Inverter: 53.0 x 47.4 x 16.5 cm

• Net weight of the team: 16.5 kg

Frequently Asked Questions (FAQ)

1. Can you install the Fronius Symo Gen24 8.0 Plus Without buying a battery immediately? Of course. This hybrid Inverter It functions initially as a conventional high performance network connection device. Its architecture Battery Ready you assure you that you can connect a lithium battery In the future directly, without the need to modify the main wiring or add external chargers.
2. What models of accumulators are compatible with this inverter of 8000W? The GEN24 PLUS series is approved exclusively to work with the High voltage lithium batteries range BYD Battery-Box Premium HVS and HVM. It is not compatible with low voltage (48V) batteries or with lead or gel systems.
3. Why is the Active Cooling system crucial in this model? By simultaneously managing high energy flows up to 8kw among the , the network and batteries, the internal components generate heat. The system Active Cooling of Fronius It uses an active dissipation by forced ventilation that avoids overheating (derating), maintaining maximum efficiency and prolonging the life of electronics.
4. How do you manage the inverter The zero pouring to the network? If your installation produces more energy than you consume and want to avoid surplus injection (by regulations or delays in legalization), the inverter Reduce its power instantaneously. To activate this function, it requires communication with the optional accessory Fronius Smart Meter.
