Inverter Solar Fronius Symo Gen24 10.0 Plus | Hybrid Inverter Three-phase with electric backrest

Fronius Symo Gen24 10.0 Plus: maximum power and total three-phase backrest

The optimization of a modern photovoltaic installation in three-phase networks with high energy demands requires a nucleus inverter robust and versatile. The hybrid Inverter Fronius Symo Gen24 10.0 Plus assume this control with maximum industrial precision, synchronizing the continuous energy of your solar with the three phases of the network. This allows prioritizing the instantaneous consumption of heavy appliances or machinery and intelligently derive surpluses to batteries to ensure a clean supply during night hours.

Continuity of supply: PV Point and Full technologies BackUp

The great competitive advantage of the platform Gen24 plus in front of the inverters traditional network three-phase is your ability to maintain power supply against public distribution network through your options backUp:

• PV POINT (integrated series): It is an automated emergency output capable of providing up to 3 kW of single-phase power during solar radiation hours. If a light cut occurs, it allows to directly feed essential consumption (such as refrigerators, routers, lighting systems or chargers) using the direct production of the solar panels, with or without connected accumulators.

• Full BackUp (Advanced): Thanks to its high power of 10kw, when combining it with an external switching box and lithium batteries, the inverter it assumes the total control of the installation in milliseconds. This allows to feed all the three-phase circuits of the home or business transparently before a supply cut of the general electrical network.

Advanced Shadow Management and New Generation Design

On Tienda Solar we bet on teams that simplify the technical deployment and ensure a long service life. The Symo Gen24 range replaces the old Snapinverter structure by an ultra-lobbish and compact chassis with rapid closure screws of a quarter turn, achieving an ideal IP66 degree for installations both indoors and the weather. Thanks to his 2 independent MPPT followers, Tolerate Strings configurations on roofs with different orientations (such as East-West Structures). In the presence of partial shadows caused by trees or chimneys, its intelligent algorithm Dynamic Peak Manager performs a continuous scan of the I-V curve to ensure your photovoltaic plates always operate at your point of maximum performance under CE certificate.

Technical specifications (model Symo Gen24 10.0 Plus):

• Nominal output power (AC): 10000 W (10 kW)

• Maximum input power (DC): 15000 W (excellent margin for oversizing solar)

• Number of MPPT followers: 2

• Maximum efficiency Inverter: 97,9%

• Compatible batteries: High voltage accumulators BYD Battery-Box Premium HVS / HVM

• Battery input voltage range: 150 V - 500 V

• Connection to Network: Three-phase (380V / 400V)

• Degree of environmental protection: IP66 (total sealing against dust and powerful water jets for external installation)

• Serial connectivity: WLAN (WiFi), Ethernet (LAN), 2x RS485 (Modbus RTU), Digital Tickets / Outputs for Smart Charging Management

• Refrigeration system: Intelligent forced ventilation (Active Cooling)

• Dimensions of the Inverter: 53.0 x 47.4 x 16.5 cm

• Net weight of the team: 16.5 kg

Frequently Asked Questions (FAQ)

1. Is it mandatory to install a battery to use the Fronius Symo Gen24 10.0 Plus? No, this hybrid Inverter can operate perfectly as a inverter connecting a conventional 10KW three-phase network in a first phase of the installation. As a team Battery Ready, it allows you to integrate a lithium battery in the future directly, without having to change the inverter neither add additional load components.
2. What lithium battery brands are compatible with this 10000W equipment? The line GEN24 plus three-phase is approved to work in perfect harmony with the high voltage lithium batteries brand BYD, specifically the series BYD Battery-Box Premium HVS and HVM. It is not compatible with standard low voltage (48V) batteries or with ancient lead-acid technologies.
3. How does the PV Point emergency output work if I do not have a battery installed? If you suffer a network blackout during the day and your solar they are receiving radiation, the inverter automatically active PV POINT. You can extract from there to 3000W of power to feed critical consumption using directly the electricity generated by your at that very moment.
4. Why is the Active Cooling system superior to passive cooling? By centralizing the high-phase photovoltaic conversion of great power and the management of battery charge cycles, the internal components accumulate temperature. The system Active Cooling emple a smart front fan that forced dissipating heat, avoiding overheating performance losses (derating) And substantially extending the useful life of all electronics.
